TAIWAN PANIO GMS06_1616_02


16×16 HDMI to HDBaseT Matrix Switcher

Professional 4K Seamless Switching & Long-Distance Transmission


Products / Modular Matrix

16×16 HDMI to HDBaseT Matrix

Provides 16 HDMI inputs and 16 HDBaseT outputs, supporting long-distance transmission up to 100 meters over CAT6 cable. Ideal for control centers, conference systems, and video wall applications requiring seamless matrix routing.

Centralized Control & Integration

Supports front-panel operation, dual RS-232 ports, IR, and TCP/IP (WEB UI) control for easy integration with centralized AV management systems.

Advanced EDID & HDCP Management

Automatic EDID detection ensures optimal display compatibility and HDCP compliance for stable 4K signal transmission.

High-Performance HDBaseT Transmission

Delivers uncompressed 4K signal, audio, and control data via single CAT6 cable to HDBaseT receivers.

Preset Scene Memory

Stores up to 16 user-defined presets for fast recall, suitable for exhibition venues, broadcast studios, and security monitoring systems.

16x16 HDMI to HDBaseT Modular Matrix Switcher

Example based on the GMS06 Standard Application Diagram, where the output section features 16 HDBaseT Extension Ports designed for long-distance signal transmission and professional AV integration.

Feature
  • This product is equipped with the built-in PANIO certification mechanism, ensuring compliance with international professional standards in safety, stability, and quality, while providing users with reliable and efficient assurance.
  • Equipped with 16 HDMI inputs, 16 HDBaseT outputs, and 16 HDBaseT receivers.
  • Supports 4K×2K @30Hz Ultra HD resolution.
  • Complies with HDMI 1.4 and HDCP 1.4 standards.
  • Seamless switching, matrix routing, and multi-view wall mode supported.
  • Transmission distance up to 70m / 100m via CAT6 (using HDBaseT extension modules).
  • Automatic power-failure memory and recovery.
  • Supports front-panel, IR, RS-232, and WEB UI control.
  • Interface bandwidth: 10.2 Gbps total.
  • 19″ rack-mount chassis — professional TAIWAN engineering quality.
16x16 HDMI to HDBaseT Modular Matrix Switcher


This product is equipped with the built-in PANIO certification mechanism, ensuring compliance with international professional standards in safety, stability, and quality, while providing users with reliable and efficient assurance.

Specification

Model NameTAIWAN PANIO GMS06_1616_02
Input16 HDMI ports
Output16 HDBaseT ports, Must be used in conjunction with compatible receivers.
HDBaseT Receiver • HDMI Output: 1 × HDMI Type-A (supports up to 4K @30Hz)
• HDBaseT Input: 1 × RJ45 port (receives uncompressed HDMI + RS-232 + IR)
• IR Port: 1 × 3.5mm jack (bidirectional IR transmission)
• RS-232 Port: 1 × Phoenix connector (bidirectional control)
Transmission DistanceIt supports a selectable 70 m or 100 m transmission distance, and the output must be paired with a receiver extender.
Resolution3840×2160 @30Hz / 1920×1080 @60Hz
Bandwidth10.2 Gbps total
ControlFront panel, IR remote, Dual RS-232, TCP/IP (WEB UI)
Status DisplayLED display panel
Power Consumption3U: 75 W (Max)
Power SupplyAC 100 – 240 V 50/60 Hz
Dimensions3U chassis 445 × 309 × 133 mm (L×W×H)
WeightApprox. 10.8 kg

Note:

  • Use certified CAT6 cables for best HDBaseT performance.
  • Ensure matched HDBaseT receivers for optimal compatibility.
  • Use only original PANIO power accessories.
  • Contact TAIWAN PANIO technical support for expansion or firmware updates.
  • Remote control battery not included.

Package Contents

  • 1 × TAIWAN PANIO GMS06_1616_02 Main Unit
  • 16 × HDBaseT Receivers
  • 1 × Power Cord
  • 1 × Remote Control (Battery not included)
  • 1 × User Manual
