[ KF16U ] 16-Port PS/2&USB Combo Free A+ KVM Switch
offers an ideal enterprise 16 ports KVM switch solution for company server room or testing facilities.PANIO Combo Free A+ 16 ports USB & PS/2 KVM switches feature the patented design of the availability of USB & PS/2 interface connection, user friendly OSD utility, Daisy chain function, and the flexibility of Firmware-Upgradable function.
Console your Keyboard/Mouse via PS/2 and/or USB at will.
Connect computers via PS/2 and/or USB at will.
Supports Windows 98SE/ME/2000/XP/Vista/7/2003 Server, Linux, Mac OS9/OSX and Sun Micro System
On-Screen-Display (OSD) & Cascade Chain functions.
OSD is intuitive menus driven for quick and efficient navigation.
Supports Daisy chain with 3 level cascades: up to 3 levels; control up to 64/256/4096 PCs, from a single console; cascaded units don't need special configuration.
Emulates PS/2 or USB keyboard on each PC to allow your computers to boot normally without a keyboard error.
Supports hot-pluggable. All devices connected to the KVM can be added or removed at any time, without shutting the unit down.
Supports 3 types of switching:
Hardware Push Button.
Hot-Keys on PS/2 and/or USB of keyboard.
Menu driven OSD (On Screen Display).
Supports Auto-Scan function to switch video inputs automatically among computers in preset intervals sequentially by OSD menu driven.
Supports LED display for PC and/or server status monitoring.
Supports VGA resolutions up to 2048 x 1536.
Supports Beeper during Switching enabled.
Fully compliant with the USB 1.1/ 2.0 specification.
Rack Mountable in 19” system tack (1U).
KVM firmware is upgradeable via on-board mini-USB download connector and external mini-programmer.
Patent No. TW M 284961, DE 20 2006 002 295.3, ZL 2005 2 0132700.2
1 x KF16U
16 x Custom combo 4-in-1 cable-1.8m (PS/2+USB KVM Cable)
1 x Rack Mount Kit
1 x Power adaptor
1 x User’s Manual

Number Of Computers Controlled


Selection Method

Push Button and Hot-Key (PS/2 / USB Keyboard)
Or On-Screen-Display (OSD)


Red for PC Selection
Green for PC On-Line ready

PC Connectors


16 x HDB-15 female


( PS/2 & USB signal combined )

Console Ports


1 x 6 pin mini-DIN female


1 x 6 pin mini-DIN female


1 x HDB-15 female


1 x USB – A type female


1 x USB – A type female

Auto-Scan Interval

Adjustable time setting by OSD menu driven

DDC, DDC2,DDC2B monitor

Yes (Max. Resolution up to 2048 x1536 )

Hot Swappable


Operating systems supported

Windows 98SE/ME/2000/XP/Vista/7/2003 Server, Linux, Mac OS9/OSX and Sun Micro System


By external power adaptor

Dimensions (L X W X H)

44 x 15.7 x 4.5 cm

Unit Weight


Housing material


Operating Temperature

32~ 122 ° F (0~ 50 ° C )



Firmware upgrade connector

Mini USB female
