[ UE60 ] USB1.1 Extender - 60m
UE60 lets you locate your USB device or hub up to 60m (198 ft) from you computer, overcoming the typical USB cable limitation. It conditions the USB signals to communicate up to 60m using low-cost Cat 5/Cat 5e/Cat 6 cable.
USB 1.1 compliant
Provides support for any full-speed (12Mb/s) or low-speed (1.5Mb/s) USB devices
Extends the transmission distance of a USB device up to 60m (198 ft) using Cat 5/ Cat 5e/ Cat 6 cabling
Embedded USB 1.1 Transceivers prevent signal loss
Lowest cost solution for extending USB signals
No additional installation software required
LED indicates when additional external power supply needed
Multiplatform support: Windows 2000/XP/ Vista 、Mac
1 x Local Unit
1 x Remote Unit
Model UE60
Connectors Local Unit
1 x USB Type A Male (White) , 1 x RJ-45 Female
Remote Unit 1 x USB Type A Female (White) , 1 x RJ-45 Female
Built-in Cable length (Local) 30cm (1')
Signal Range 60m (198')
Supply Current Drawn 20mA
Environment Operating Temperature 0°C ~ 40°C
Storage Temperature -40 °C ~ 85°C
