Quad Multi-Viewer Switch
4 HDMI、2 DP、1 VGA+Audio Input 1 HDMI and 1 Audio Output
CQ7100
About CQ7100
【CQ7100】 supports 3 kinds of signals: HDMI x 4ports + DP x 2ports + VGA+3.5mm x 1 port, Total 7 ports signal input, and HDMI x 1port + 3.5mm x 1port output. The maximum output resolution up to 1920*1080 @60HZ. Built-in multiple presentation mode: 4 split screen / 2 split screen / PIP, POP / full screen.
In addition, it is mainly used in where need to use a single display unit simultaneously display multiple HD signals workplace like video conferencing, teaching, exhibitions, etc.
Support 1 X VGA, 2 X DP, 4 X HDMI (3 X compatible MHL) signal input.
Support 1 X HDMI output, resolution up to 1920*1080 @60HZ.
Input signals are all included audio, support audio and video synchronization switching, four-division mode audio independent switching.
Built-in multiple presentation mode: 4 split screen / 2 split screen / PIP, POP / full screen.
Control method: Panel button / Remote control / RS-232.
1 x 12V Power Supply
1 x IR (Without battery)
1 x User Manual
| MODLE NAME | CQ7100 |
|---|---|
| Input port | 4 x HDMI, 2 x DP, 1 x VGA, 1 x 3.5mm |
| Output port | 1 x HDMI, 1 x 3.5mm |
| Video Resolution | 1080P @60Hz |
| Color depth | 24bit, 1677 ten thousand |
| POP, PIP mode | Fixed model |
| Control mode | Panel button / Remote control / RS-232 |
| Material | Metal |
| Power Supply | AC 110V-240V 50/60HZ DC 12V |
| Dimension ( L x W x H ) | 278 × 166 × 36 mm |
| Mass (Main unit) | 1.2Kg |
Diagram
