Wall Plate 4K Multi-Format HDBaseT Video Extender with 2-Input Switch

Supports HDMI, VGA + Audio, PoC, and EDID Management


Products / HDMI Extender

HDBaseT Transmission over Cat6

HV-A: Up to 100 m at 1080p 60Hz; up to 70 m at 4K 30Hz.
HV-B: Up to 70 m at 1080p 60Hz; up to 35 m at 4K 30Hz.

4K 30Hz Resolution

Supports up to 3840 × 2160 @ 30Hz (4K 30Hz).

Dual Inputs (Auto Switching)

Built-in HDMI and VGA + 3.5mm audio inputs with automatic source detection.

PoC Single-Side Power

Power the system from one side using PoC (Power over Cable).

EDID Management

The transmitter provides comprehensive EDID management for reliable compatibility.

PANIO HV wall plate 4K multi-format HDBaseT extender with HDMI/VGA inputs and 2-input switch

Features

  • Transmits HDMI or VGA + 3.5mm audio signals using HDBaseT technology.
  • HV-A: Up to 100 m at 1080p 60Hz; up to 70 m at 4K 30Hz.
  • HV-B: Up to 70 m at 1080p 60Hz; up to 35 m at 4K 30Hz.
  • Elegant wall-plate design—cabling is hidden behind the panel for a clean installation.
  • Built-in automatic EQ adjustment for optimal signal clarity.
  • Auto-detection selects the most recently connected video source.
  • Plug-and-play—no drivers or software installation required.
  • Compliant with HDMI 1.4b and HDCP 1.4 standards.
  • Optional TV receivers support remote playback and display.
  • Supports PoC (single-side power) for simpler deployment.
  • Can connect directly to PANIO GMS series matrix switchers—no additional receiver required.
4K 30Hz supported resolution for PANIO HV HDBaseT wall plate extender

Specifications

Model Name HV
Input 1 × HDMI / 1 × VGA + 3.5mm audio
Output 1 × RJ-45 port (HDBaseT)
Video Resolution 4K 30Hz / 1080p
Transmission Distance HV-A: Up to 100 m at 1080p 60Hz; up to 70 m at 4K 30Hz.
HV-B: Up to 70 m at 1080p 60Hz; up to 35 m at 4K 30Hz.
Standards HDMI 1.4b, HDCP 1.4
Signal Transmission Rate 10.2 Gbps
Cable Length (HDMI) Max 5 m for input and output HDMI cables
Power Supply DC 12V 1.5A
Dimensions 86 × 86 × 38 mm (L × W × H)
Item Weight 180 g

Notes

  • Use certified 4K HDMI cables to ensure optimal performance.
  • For stability, use the original certified power adapter.
  • If integrating with third-party devices, please contact us to confirm compatibility.
  • Use Cat6 network cable (all 8 conductors connected).
  • This extender does not work through standard network switches.

Package Contents

  • 1 × HV transmitter
  • 1 × 12V 1.5A power adapter
  • 1 × User manual
